Evasive Action CB(C-2254) Aircraft Detail
 Information
 Launch Log
|
|
|
Rocket/Aircraft Details
|
| Name: |
Evasive Action CB |
| Aircraft Type: |
Rocket |
| Manufacturer : |
LOC Precision |
| Model: |
EZI65 |
|
|
Aircraft Configuration Details
Original Configuration
| Original Configuration (Default/Original Configuration )
|
| Constructed/Completed: |
2011/02/19 |
| Config. Status: |
Damaged (terminal) |
| Height: |
56.50in |
| Payload bay: |
10.00in |
| Diameter: |
3.90in |
| CP: |
48.00in from tip |
| Dry weight : |
0.90kg |
|
| Fins: |
Plywood |
| Body: |
Paper/Cardboard |
* Special purpose electronics
|
* Onboard video
|
|
| Main Stage:
1 x 38mm, Retention ring (eg: Aeropack, Slimline)
|
| Recovery event 1 configuration:
Motor discharge
1 x
36.00in. Dome chute
|
|
|
|
|
Launch log
| Flight |
Alt. |
Motor |
Recovery |
Status |
Cert. |
Notes |
3. 2010/07/04 "L3 Cert Attempt"
Cfg.:Original Configuration
VIPE 2010 St Prime,QC,CA
|
1000.00ft Estimated |
38mm Cesaroni 765-J330-9s
|
Dome chute 36.00in
|
Fail (Disintegrated) |
-- |
Level 3 certification attempt. CB was serving as back-up to AMF that day, since I had not installed the required electronics on AMF. The rocket disintegrated 1.8 seconds into the flight. Rocket can no longer be flown. |
|
2. 2010/05/24 "Borderline G Flight"
Cfg.:Original Configuration
Fusée Fête 2010 St Pie de Guire,QC,CA
|
472.00ft Altimeter |
38mm Cesaroni 117-G69-8s
|
Dome chute 36.00in
|
Success |
-- |
Last flight of the weekend for my fleet. Deployment occurred very late and rocket's fin was considerably damaged in the incident. Fins have been repaired and rocket is set for full repainting before next flight. |
|
1. 2010/05/24 "L2 Cert Flight"
Cfg.:Original Configuration
Fusée Fête 2010 St Pie de Guire,QC,CA
|
2522.00ft Altimeter |
38mm Cesaroni 413-I236-10s
|
Dome chute 36.00in
|
Success |
-- |
Very impressive. Borderline for the rocket: top speed was 585mph! |
|
| Count: 3 |
|
Web links, pictures, documents & more
|
|
Media
